Description
| Model | ModFree Base Edition |
ModFree Stretch Edition |
ModFree Deluxe Edition |
|---|---|---|---|
| Model Number | IW-CS-MFBASE-BLK | IW-CS-MFSTRE-MNC | IW-CS-MFDELU-BLK |
| Color | Black | White, Black, Orange | Black |
| Case Type | Full Tower | ||
| Materials | SECC, Tempered Glass, ABS | SECC, PMMA, ABS | SECC, Tempered Glass, ABS |
| M/B Compatibility | 12″ x 13″ E-ATX, ATX, Micro-ATX, Mini-ITX | ||
| Expansion Slots | 9 x PCI-E | ||
| Maximum Compatibility | GPU Card Length: 369 mm or 345 mm with Fan pre-installed | GPU Card Length: 369 mm or 440mm with Mod-III and Fans pre-installed | |
| CPU Heatsink Height: 200 mm | |||
| I/O Ports | 1 x USB 3.2 Gen 2×2 Type-C 2 x USB 3.2 Gen 1 HD Audio Combo (CTIA – SPK/MIC) |
||
| Internal Drive Bays | 2 x 2.5″ 1 x 3.5″ or 2 x 2.5″ with HDD Bracket |
||
| Thermal Solution Compatibility | Air Cooling Fans: Front: 2 x 120 / 140 mm Top: 2 x 120 / 140 mm Rear: 1 x 120 / 140 mmWater Cooling Radiator: Front: 1 x 240 / 280 mm Top: 1 x 240 mm |
Air Cooling Fans: Front: 3 x 120 / 140 mm Top: 2 x 120 / 140 mm Rear: 1 x 120 / 140 mmWater Cooling Radiator: Front: 1 x 360 / 420 mm Top: 1 x 240 mm |
Air Cooling Fans: Front: 3 x 120 / 140 mm Top: 3 x 120 / 140 mm Rear: 1 x 120 / 140 mmWater Cooling Radiator: Front: 1 x 360 / 420 mm Top: 1 x 360 / 420 mm |
| Power Supply Compatibility | PSII: ATX12V – Length up to 390 mm or 240 mm with Hard Drive Tray Installed |
||
| Product Dimensions (L x W x H) |
411.5 x 261.8 x 531 mm 16.2 x 10.3 x 20.9″ |
513 x 263 x 531.5 mm 20.2 x 10.4 x 20.9″ |
511.6 x 261.8 x 631 mm 20.1 x 10.3 x 24.8″ |
| Package Dimensions (L x W x H) |
532 x 342 x 630 mm 20.9 x 13.5 x 24.8″ |
640 x 354 x 642 mm 25.2 x 13.9 x 25.3″ |
642 x 352 x 740 mm 25.3 x 13.9 x 29.1″ |
| Net Weight | 9.2 kg / 20.28 lbs | 9.7 kg / 21.38 lbs | 14 kg / 30.86 lbs |
| Gross Weight | 11.4 kg / 25.13 lbs | 12.5 kg / 27.56 lbs | 17 kg / 37.48 lbs |
