Description
ASUS TUF Gaming Radeon™ RX 6700 XT OC Edition 12GB GDDR6 is a supreme stalwart of cooling and durability.
- Axial-tech fan design has been enhanced with more fan blades and a new rotation scheme.
- Dual ball fan bearings can last up to twice as long as sleeve bearing designs.
- An all-aluminum shroud, reinforced frame, and metal backplate enhance durability.
- MaxContact heat spreader features a super flat surface for improved thermal transfer.
- A 144-hour validation program puts cards through a series of stringent tests to ensure compatibility with the latest games.
- A vented backplate prevents hot air from recirculating through the cooling array.
Specifications
Model
TUF-RX6700XT-O12G-GAMING
Graphic Engine
AMD Radeon RX 6700 XT
Bus Standard
PCI Express 4.0
OpenGL
OpenGL®4.6
Video Memory
12GB GDDR6
Engine Clock
OC mode : Up to 2622 MHz (Boost Clock)/Up to 2534 MHz (Game Clock)
Gaming mode : Up to 2622 MHz (Boost Clock)/Up to 2514 MHz (Game Clock)
Stream Processors
2560
Memory Speed
16 Gpbs
Memory Interface
192-bit
Resolution
Digital Max Resolution 7680 x 4320
Interface
Yes x 1 (Native HDMI 2.1), Yes x 3 (Native DisplayPort 1.4a), HDCP Support Yes (2.3)
Maximum Display Support
4
NVlink/ Crossfire Support
Yes
Accessories
1 x TUF Certificate of Reliability
1 x Collection Card
1 x Speedsetup Manual
Software
ASUS GPU Tweak II & Drivers: please download all software from the support site.
Dimensions
322 x 152 x 58 mm
12.68 x 5.98 x 2.28 inches
Recommended PSU
650W
Power Connectors
2 x 8-pin
Slot
2.9 Slot
AURA SYNC
ARGB
