Amd Am5 Ryzen 9 9950x 16 Cores 32 Threads 4.3 Ghz up to 5.7 Ghz boost with onboard graphics
\nGeneral Specs \n
\n
\n
\n
\n
\nName AMD Ryzen™ 9 9950X
\nFamily Ryzen
\nSeries Ryzen 9000 Series
\nForm Factor Desktops , Boxed Processor
\nMarket Segment Enthusiast Desktop
\nAMD PRO Technologies No
\nRegional Availability Global
\nFormer Code name Granite Ridge AM5
\nProcessor Architecture Zen 5
\n# of CPU Cores 16
\nMulti threading (SMT) Yes
\n# of Threads 32
\nMax. Boost Clock Up to 5.7 GHz
\nBase Clock 4.3 GHz
\nL1 Cache1280 KB
\nL2 Cache16 MB
\nL3 Cache64 MB
\nDefault TDP170W
\nProcessor Technology for CPU Cores TSMC 4nm FinFET
\nProcessor Technology for I/O Die TSMC 6nm FinFET
\nPackage Die Count 3
\nUnlocked for Overclocking Yes
\nAMD EXPO™ Memory Overclocking Technology Yes
\nPrecision Boost Overdrive Yes
\nCurve Optimizer Voltage Offsets Yes
\nAMD Ryzen™ Master Support Yes
\nCPU SocketAM5
\nSupporting Chipsets A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850
\nCPU Boost Technology Precision Boost 2
\nInstruction Setx86-64
\nSupported Extensions AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64
\nThermal Solution (PIB) Not Included
\nRecommended Cooler Liquid cooler recommended for optimal performance
\nMax. Operating Temperature (Tjmax) 95°C
\nLaunch Date08/15/2024
\n*OS Support Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit
\nConnectivity
\n
\n
\n
\n
\nNative USB 3.2 Gen 2 (10Gbps) 4
\nNative USB 2.0 (480Mbps) 1
\nPCI Express® Version PCIe® 5.0
\nNative PCIe ® Lanes (Total/Usable) 28 , 24
\n
\n
\nAdditional Usable PCIe Lanes from Motherboard
\n
\n
\n
\n
\n
\nX870E 8x Gen4
\n
\n
\nX870 4x Gen4
\n
\n
\nX670E 12x Gen4
\n
\n
\nX670 12x Gen4
\n
\n
\nB650E 8x Gen4
\n
\n
\nB650 8x Gen4
\nNVMe Support Boot , RAID0 , RAID1 , RAID5 , RAID10
\nSystem Memory Type DDR5
\nMemory Channels 2
\nMax. Memory 192 GB
\nSystem Memory Sub type UDIMM
\n
\n
\nMax Memory Speed
\n
\n
\n
\n
\n
\n2x1R DDR5-5600
\n
\n
\n2x2R DDR5-5600
\n
\n
\n4x1R DDR5-3600
\n
\n
\n4x2R DDR5-3600
\nECC Support Yes (Requires mobo support)
\nGraphics Capabilities
\n
\n
\n
\n
\nGraphics Model AMD Radeon™ Graphics
\nGraphics Core Count 2
\nGraphics Frequency 2200 MHz
\nUSB Type-C® DisplayPort™ Alternate Mode yes
\nProduct ID's
\n
\n
\n
\n
\nProduct ID Boxed100-100001277WOF
\nProduct ID Tray100-000001277
\nKey Features
\n
\n
\n
\n
\n
\n
\nSupported Technologies AMD EXPO™ Technology , AMD Ryzen™ Technologies
\nAmd Am5 Ryzen 9 9950x 16 Cores 32 Threads 4.3 Ghz up to 5.7 Ghz boost with onboard graphics
- Product Code: cp-ay9950x+g
- Availability: 2-3 Days
-
R13,831.74
- Ex Tax: R12,027.60
