| Model |
A5 |
| Model Number |
IW-CS-A5BLK-1AM120S
IW-CS-A5WHI-1AM120S |
| Colors |
Black, White |
| Case Type |
Mid Tower |
| Materials |
SECC, Tempered Glass, PC-ABS |
| M/B Compatibility |
12" x 11" E-ATX, ATX, Micro-ATX, Mini-ITX |
| Expansion Slots |
7 x PCI-E |
| Maximum Compatibility |
GPU Length: 340 mm
CPU Heatsink Height: 162 mm |
| I/O Ports |
1 x USB 3.2 Gen 2x2 Type-C
2 x USB 3.2 Gen 1
HD Audio Combo (CTIA – SPK/Mic) |
| Internal Drive Bays |
2 x 3.5" / 2.5"
2 x 2.5" |
| Thermal Solution Compatibility |
Air Cooling Fans:
Top: 2 x 120 mm
Rear: 1 x 120 mm
Bottom: 2 x 120 mm
(1 InWin Mercury AM120S Fan Included)
Water Cooling Radiator:
Top: 1 x 240 mm |
| Power Supply Compatibility |
PSII: ATX12V
- Length between 140 - 200 mm
(PSUs longer than 170 mm will need to build with GPUs 280 mm or shorter) |
| Product Dimensions
(L x W x H) |
399 x 215 x 407 mm
15.7 x 8.5 x 16" |
| Package Dimensions
(L x W x H) |
473 x 277 x 483 mm
18.6 x 10.9 x 19" |
| Net Weight |
5.86 kg / 12.92 lbs |
| Gross Weight |
6.94 kg / 15.30 lbs |
