| Model |
909 |
| Part Number |
IW-909C-BLACK / IW-909C-SILVER |
| Color |
Black,Silver |
| Case Type |
Full Tower |
| Case Material |
Tempered Glass, Aluminum |
| M/B Compatibility |
12" x 13.4" E-ATX, ATX, Micro-ATX, Mini-ITX |
| Expansion Slots |
PCI-E x 8 |
| Maximum Compatibility |
VGA Card Length: 320mm Maximum
VGA Card Height: 180mm Maximum
CPU Heatsink Height: 175mm |
| Front Ports |
1 x USB 3.1 Gen 2 Type-C
2 x USB 3.0
1 x USB 2.0
LED Light Button
HD Audio |
| Internal Drive Bays |
4 x 2.5"/3.5"
6 x 2.5" |
| Thermal Solution Compatibility |
2 x 120 or 140mm Front Fan / 280mm Radiator
1 x 120mm Middle Fan / 120mm Radiator
3 x 120mm or 2 x 140mm Rear Fan / 360mm Radiator
2 x 120 or 140mm Bottom Fan / 240mm Radiator |
| Power Supply Compatibility |
PSII: ATX12V and EPS12V
- Length: 220mm Maximum |
| Product Dimension
(H x W x D) |
540 x 230 x 575mm
21.3" x 9.1" x 22.6" |
| Product Dimension
(H x W x D)
with screw height |
545 x 250 x 586mm
21.5" x 9.8" x 23.1" |
| Package Dimension
(H x W x D) |
370mm x 707mm x 672mm
14.6" x 27.9" x 22.6" |
| Net Weight |
17kg / 37.48lb |
| Gross Weight |
20.6kg / 45.42lb |
