| Model |
N515 |
| Model Number |
IW-CS-N515BLK-1AL120 |
| Colors |
Black |
| Case Type |
Mid Tower |
| Materials |
SECC, ABS, Tempered Glass |
| M/B Compatibility |
12" x 13" E-ATX, ATX, Micro-ATX, Mini-ITX |
| Expansion Slots |
7 x PCI-E |
| Maximum Compatibility |
VGA Card Length: 385 mm
CPU Heatsink Height: 160 mm |
| I/O Ports |
1 x USB 3.2 Gen 2x2 Type-C
2 x USB 3.2 Gen 1
HD Audio Combo+Mic |
| Internal Drive Bays |
2 x 3.5" / 2.5"
2 x 2.5" |
| Thermal Solution Compatibility |
Air Cooling Fans:
Top: 3 x 120 mm
Rear: 1 x 120 mm
Bottom: 3 x 120 mm
Front: 2 x 120 mm
(1 InWin Luna AL120 Fan Included)
Water Cooling Radiator:
Top: 1 x 360 mm (Maxi. Length 405mm & Thickness 80mm)
Rear: 1 x 120 mm
Bottom: 1 x 360 mm (Slim)
(Remove Graphics Card Holder)
Front: 1 x 240 mm |
| * Number of fans pre-installed may vary based on different regions |
| Power Supply Compatibility |
PSII: ATX12V
- Length up to 200 mm |
| Product Dimensions
(L x W x H) |
515 x 225 x 502 mm
20.3 x 8.8 x 19.7" |
| Package Dimensions
(L x W x H) |
610 x 335 x 572 mm
24 x 13.1 x 22.5" |
| Net Weight |
11.65 kg / 25.68 lb |
| Gross Weight |
13.73 kg / 30.27 lb |
