Technical Specs

Colors Black - White - Red - Blue - Yellow ICON™ 2.8" TFT display, 240 x 320 Fan Controller 4pin header x 4 - 12v/7v/5v Micro ATX, Mini-ITX motherboards (5 expansion slots)

Maximum CPU Cooler Height up to 170mm (6.7inch)

Maximum Length of Graphics Card Support up to 380mm (15inch)

Maximum Width of Graphics Card Support up to 140mm (5.5inch)

Power Supply length up to 220mm

3.5” HDD Slots 4 (two removable cages with 2 tool-free slots each)

2.5” SSD Slots 4 (one removable cage with 2 tool-free slots each, one slot next to Mainboard, one slot behind PSU) Click-on Top Dust Filter 360mm magnetic Front Dust Filter 360mm magnetic Bottom Dust Filter

Top Cooling 120mm x 2 or 140mm x 2

Front Cooling 120mm x 3 or 140mm x 2

Bottom Cooler 120mm x 1 or 140mm x 1

Rear Cooler 120mm x 1 (included)

Upper Radiator 280mm, 240mm, 140mm, 120mm

Front Radiator 360mm, 280mm, 240mm, 140mm, 120mm

Lower Radiator 140mm, 120mm

Rear Radiator 120mm USB 3.0 x 2 I/O, HD Audio

Dimensions (LxWxH mm - in) 205 x 470 x 480mm - 8.07 x 18.50 x 18.89inch

Material Steel, Plastic

Weight 6.7Kg - 14.8lbs

Extras BitFenix ​​ICON™ Display (Core version comes without Display),

• Pump bracket
• Reservoir bracket
• PSU cover
• Fan Controller
• Magnetic Dust Filter
• 3 tool-free and modular HDD/SSD Enclosures

Liquid Cooling Radiator Locations:

Top 280 61mm (36mm+25mm)

Top 240 85mm (60mm + 25mm) 110mm (60mm + 50mm)

Top 140 80mm (55mm + 25mm) 80mm (30mm + 50mm)

Top 120 105mm (80mm + 25mm) 130mm (80mm + 50mm)

Front 360 85mm (60mm + 25mm) *1 *2 85mm (35mm + 50mm) *1 *2

Front 280 85mm (60mm + 25mm) *1 85mm (35mm + 50mm) *1

Front 240 85mm (60mm + 25mm) *1 85mm (35mm + 50mm) *1

Front 140 85mm (60mm + 25mm) *1 85mm (35mm + 50mm) *1

Front 120 105mm (80mm + 25mm) 130mm (80mm + 50mm)

Bottom 140 90mm (65mm + 25mm) 90mm (40mm + 50mm)

Bottom 120 105mm (80mm + 25mm) 130mm (80mm + 50mm)

Rear 120 105mm (80mm + 25mm) 130mm (80mm + 50mm) *1 - with 300mm VGA *2

Max 360 radiator height = 406mm

Note: Most configurations require one or several of the storage cages to be removed Aegis (Icon Display)
